Korg minilogue User Manual

24
Button Voice mode Action VOICE MODE DEPTH knob eect
6 DELAY
Voices 2, 3, and 4 will play in
delayed sequence after voice 1
plays.
[1/192...1/4]
Turning the knob to the right will
make the delay time longer.
7 ARP
Uses the arpeggiator to play up
to 4 voices.
[MANUAL 1, MANUAL 2, RISE 1,
RISE 2, FALL 1, FALL 2, RISE FALL 1,
RISE FALL 2, POLY 1, POLY 2, RAN
-
DOM 1, RANDOM 2, RANDOM 3]
Selects the arpeggiator type.
8 SIDE CHAIN
Lowers the volume of the pre-
viously-played voice when a
new voice is played.
[Depth 0...1023]
Turning the knob to the right will
increase the volume range by which
the previously-played voice is re
-
duced.

Korg minilogue Specifications

General

Product type	Analog synthesizer
Product color	Silver
User presets quantity	100
Keyboard number of keys	37
Maximum polyphony (notes)	4
Display type	OLED
Built-in display	Yes
Headphone outputs	1
DC input voltage	9 V
Power source type	AC

Weight and Dimensions

Depth	300 mm
Width	500 mm
Height	85 mm
Weight	2800 g
