160
Global
MIDI: MIDI Out Channels
MIDI: MIDI Out Channels
In this page, you can assign Pa300 tracks to any of the MIDI
channels sent to the USB Device port. All these parameters can
be saved into a MIDI Preset.
Channels
You can assign to each channel one of the following tracks:
Off No track assigned.
Lower Keyboard’s Lower track.
Upper 1…3 One of the Keyboard’s Upper tracks.
Pad 1…4 One of the Pad tracks.
Drum Style’s Drum track.
Percussion Style’s Percussion track.
Bass Style’s Bass track.
Acc 1…5 One of the Style’s Auto-accompaniment tracks.
Ply Tr 01…16 One of the Player tracks.
Chord Use this channel to send notes recognized by the
Chord Recognition engine to the USB Device
port. This is useful, for example, to control an
external Harmonizer from the Pa300, using the
Lower track to play chords, even if the track is
muted.
Control On this special channel, the Pa300 sends mes-
sages corresponding to the selected SongBook
Entry.
MIDI: Filters
Use this page to set up to 8 filters for the MIDI data received or
sent by the Pa300 on the USB Device port. All these parameters
can be saved into a MIDI Preset.
Midi In Filters
Selected MIDI IN filters. Filters are applied to all MIDI channels
at the same time.
Off No filter.
Pitch Bend Pitch Bend.
MonoTouch Mono (or Channel) After Touch.
PolyTouch Poly After Touch.
PrgChange Program Change.
SysExcl System Exclusive.
All CC All Control Change messages.
0…127 Control Change message #0…127. See “MIDI
Data” on page 358 for a list of available Control
Change messages.
Notes Note events.
Midi Out Filters
Selected MIDI OUT filters. See above for information on each
filter type.
Pa300 User Manual v150 (English).book Page 160 Saturday, March 29, 2014 5:29 PM
