Korg Pa300 User Manual

162
Global
Touch Panel Calibration
Gain
Gain of the corresponding band. Use it to make the frequencies
stronger or weaker.
Touch Panel Calibration
From time to time (for example, after loading a new operating
system), calibrating your Color TouchView™ display may be nec-
essary to make pointing more precise. If so, use this page.
1. When in this page, first touch exactly inside the set of
arrows in the upper left corner of the display.
Hint: To be more accurate, you can use a pen cap or a tablet
stylus. Do not use anything sharp (like a pencil), or you
will risk to damage the display!
2. The arrows will subsequently move to the other corners of
the display. Touch exactly inside them.
3. Finally, touch Save to confirm the new calibration.
• In case you want to exit and cancel the calibration, press
EXIT before completing the procedure.
Hint: To quickly reach this page from any other page, keep the
GLOBAL button pressed until this page appears.
Band Value
All Bands -18…0…+18dB
Pa300 User Manual v150 (English).book Page 162 Saturday, March 29, 2014 5:29 PM

Korg Pa300 Specifications

General

Polyphony	128 voices
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	Yes
Keyboard	61 keys (velocity sensitive)
Display	Color TFT LCD
Sequencer	16-track sequencer
Dimensions	1, 030 x 378.3 x 127 mm
Weight	8.35 kg
Effects Types	125 Effects types
Data Storage	USB
USB	USB to Host, USB to Device
Outputs	L/Mono, R, Headphones
Effects	125
Amplifier	2 x 13W
