Korg Pa300 User Manual

164
Global
Write Master EQ Preset dialog box
Write Master EQ Preset dialog box
Open this dialog box by selecting the Write Master EQ Preset
item from the page menu. Here, you can save current settings for
the Master EQ edit section (see starting from page 161).
Name
Name of the Master EQ Preset to be saved. Touch the (Text
Edit) button next to the name to open the Text Edit window and
modify the name.
Master EQ Preset
One of the available locations, where to save current Master EQ
settings.
Pa300 User Manual v150 (English).book Page 164 Saturday, March 29, 2014 5:29 PM

Korg Pa300 Specifications

General

Polyphony	128 voices
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	Yes
Keyboard	61 keys (velocity sensitive)
Display	Color TFT LCD
Sequencer	16-track sequencer
Dimensions	1, 030 x 378.3 x 127 mm
Weight	8.35 kg
Effects Types	125 Effects types
Data Storage	USB
USB	USB to Host, USB to Device
Outputs	L/Mono, R, Headphones
Effects	125
Amplifier	2 x 13W
