104| Using the SongBook
Pads and Keyboard Sets will also be recalled. Keyboard Set #1 will be se-
lected. Any TXT file associated with the Entry will be shown in the Lyrics
page. A Voice Preset will also be recalled (unless the lock in Global > General
Controls > Locks page will prevent it).
4 Use the START/STOP or PLAY/STOP (
) button to start and stop play-
back of the selected Style or Song.
Identifying the type of Entry
The icons in the Type column will help you identify the Entry.
Type Meaning
Style-based Entry. When chosen, it will select a Style and switch to the Style Play
mode.
MIDI Song-based Entry. When chosen, it will select a Song and switch to the
Song Play mode.
MP3 Song-based Entry. When chosen, it will select a Song and switch to the Song
Play mode.
Sorting by label/column
On top of the list you can find some labels, each one corresponding to a col-
umn of data (Type, Name, Genre, Key, Bpm, Meter…). You can choose one of
the labels to sort the list according to that type of data.
Change the order of the list
▪ Reorder the items according to a different criterion (Type, Name, Genre,
Key, Bpm, Meter…) by touching the corresponding label on top of the list.
▪ By touching the label again, the order of the items will switch between as-
cending and descending.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
