Korg PA4X User Manual

The user interface in detail |29
As an alternative, touch a numeric field and keep it held. Then move your
fingers up (or right) to increase the value, or move it down (or left) to de-
crease it.
This also includes the Tempo numeric field in various pages.
Icons
Various icons help identifying the type of a file, a folder, a Song. For example:
Icon Meaning
Folder
File of Style bank
MID le
Selected, highlighted items
Any operation on parameters, data or list entries, is executed on highlighted
items. First touch the parameter or item to select it, then execute the opera-
tion. Most parameters can be edited with the VALUE controls.
Non-available, dimmed parameters
When a parameter or command is not currently available, it is shown dimmed
on the display. This means it cannot be selected, but may become available
when a different option is selected, or you switch to a different page.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
