Korg PA4X User Manual

34| Interface basics
Selecting the musical resources
Opening a Select window
When you press one of the STYLE, SOUND SELECT, or one of the KEYBOARD
SET LIBRARY buttons, the corresponding Select window appears. For ex-
ample, this is the Sound Select window:
Pages Previous/Next
Pages
Type
Groups
Groups
Sounds
You can always exit from this window by pressing the EXIT button.
In Pa4X, Select windows stay always open until you press the EXIT button. If
you prefer they automatically close after a few seconds, or after you select
something, turn the Display Hold parameter off (see Display Hold on page
41).

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
