Korg PA4X User Manual

42| Playing the Sounds
Playing and controlling the Sounds
Playing the keyboard
The instrument’s keyboard is like a piano keyboard. Just play it!
With some Sounds, you can press the keys while they are down, and the
sound might vary (for example, you might hear more vibrato).
Using the pedals
Pedals do different things depending on how they are programmed. The
Damper pedal is just that – a damper pedal, sustaining notes until you re-
lease the pedal. The other pedal may change depending on the selected
Sound set.
Using the assignable sliders
Depending on the chosen Keyboard Set, the sliders can control different
things, like volume levels of the different Sounds, the organ drawbars or
some assignable functions. How they work is shown by the SLIDER MODE
button’s indicator.
Using the assignable switches
Depending on the chosen Keyboard Set and the assigned DNC functions,
these controllers can do different things. The switches can either ‘book’
a function, that will be triggered while playing, or enable (or disable) it by
pressing the button to ‘toggle’ it.
Indicator status Meaning
Off No DNC function assigned.
Red steady Booking DNC function available.
Red blinking Booking DNC function waiting to be executed. Then, it will return
steady.
Green steady Toggle DNC function available.
Green blinking Toggle activated. Press it again to disable it.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
