Korg PA4X User Manual

Transposing |51
Transposing
Transposing the Upper Sounds to a different octave
All Upper Sounds can be transposed to an upper or lower octave at the press
of a single button.
Transpose the Upper Sounds one octave up
▪ Press the UPPER OCTAVE + button on the control panel.
Transpose the Upper Sounds one octave down
▪ Press the UPPER OCTAVE - button on the control panel.
Reset the octave transposition
▪ Press both UPPER OCTAVE buttons together.
Transposing the whole instrument
The instrument’s key can be transposed to make singing or playing together
with another instrument more comfortable.
The transpose value is usually shown in the page header.
Transpose down from the control panel
▪ Use the TRANSPOSE > FLAT (
) button to lower the Master Transpose in
steps of one semitone.
Transpose up from the control panel
▪ Use the TRANSPOSE > SHARP (
) button to raise the Master Transpose in
steps of one semitone.
Reset transposition
▪ Press both TRANSPOSE buttons together.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
