Korg PA4X User Manual

78| Playing the Songs
Open the Song Select window from the display
▪ Touch the name of the Song on the display. You can choose either Player 1
(PLY 1) or Player 2 (PLY2) to play the Song.
Browse through the Songs
While in the Song Select window, browse through the files to find the Song
you are looking for.
Device
Current path
▪ Choose a storage device by using the Device menu.
If the Song is contained in an external USB device, connect the device to one
of the USB HOST port.
Device Type
DISK Internal memory
HD Internal HD (optional in Pa4X-61)
SD Optional internal microSD
USB-F Optional device connected to the front (F) USB HOST port
USB-R Optional device connected to the rear (R) USB HOST port
The actual name (label) of the device will appear between square brackets.
▪ Scroll the list by using the scrollbar. As an alternative, use the VALUE con-
trols (if the focus is on the Device selector, touch any item in the list before
using the dial).
▪ Open the selected folder/directory by touching the Open button.
▪ Go to the upper folder/directory by touching the Close button.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
