Korg PA4X User Manual

Choosing the Songs |79
▪ Jump to the folder/directory, containing the Song currently assigned to the
Player, by touching the Locate button.
Jump to a different alphabetical section
1 If it is not selected, touch the Name label on top of the list.
2 Keep the SHIFT button pressed and touch one of the arrows of the scrollbar
to jump to the previous or next alphabetical section.
Change the list ordering
▪ Reorder the items according to a different criterion (Type, Name, Size, Date)
by touching the corresponding label on top of the list.
▪ By touching the label again, the order of the files will switch between as-
cending and descending.
Select the Song
1 Touch the name of the Song you want to choose to highlight it.
2 Touch the Select button. If a Song is already playing, it will stop, and the new
Song will be ready to play. You will return to the Main page of the Song Play
mode.
When a Song has been selected, it will appear in the Song area.
▪ MIDI Song selected:
Meter
(Time Signature)
Current measure
Tempo
▪ MP3 Song selected:
Total time
Elapsed time
Tempo variation

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
