Korg SQ-64

21
SQ-64 Owner's Manual
■
When the TRACK button [D] is pressed
Pad position Global parameter name PARAM knob Value (initial value is in boldface) Parameter details, remarks
A-5 GATE CV PARAM1 ---, V-TRIG, S-TRIG
Set the polarity of the gate output.
PARAM2 5V, 10V
Set the voltage range for the gate output. (D1 - D8 only)
A-9 MIDI RX PARAM1 ---, CH1 - CH16 (CH10)
Set channel on which MIDI messages will be received.
PARAM2 USB OFF, USB ON
Enable/disable reception of MIDI messages from USB-MIDI.
PARAM3 MIDI OFF, MIDI ON
Enable/disable reception of MIDI messages from MIDI input.
A-10 MIDI TX PARAM1 ---, CH1 - CH16 (CH10)
Set channel on which MIDI messages will be transmitted.
PARAM2 USB OFF, USB ON
Enable/disable transmission of MIDI messages to USB-MIDI.
PARAM3 MIDI1 OFF, MIDI1 ON
Enable/disable transmission of MIDI messages to MIDI1 output.
PARAM4 MIDI2 OFF, MIDI2 ON
Enable/disable transmission of MIDI messages to MIDI2 output.
■
When the D.SUB-TRACKS button [D1] to [D16] is pressed
Pad position Global parameter name PARAM knob Value (initial value is in boldface) Parameter details, remarks
A-5 GATE CV PARAM1 V-TRIG, S-TRIG Set the polarity of the gate output..
A-9 MIDI RX
PARAM1 CH1 - CH16 (CH10) Set channel on which MIDI messages will be received.
PARAM2 ANY
, 0-127 Set MIDI note to be received.
A-10 MIDI TX
PARAM1 CH1 - CH16 (CH10) Set channel on which MIDI messages will be transmitted.
PARAM2
0-127 Set MIDI note to be transmitted.
■
When the CONTROL button is pressed
Pad position Global parameter name PARAM knob Value (initial value is in boldface) Parameter details, remarks
A-10 MIDI TX PARAM1 CH1 - CH16
MIDI TX CHANNEL
PARAM2 USB OFF, USB ON
MIDI TX USB
PARAM3 MIDI1 OFF, MIDI1 ON
MIDI TX MIDI1
PARAM4 MIDI2 OFF, MIDI2 ON
MIDI TX MIDI2
