KRACK KR Series - TABLE 1 B. Gas Defrost Unit Dimensions and Connection Sizes; TABLE 1 C. Air Defrost Unit Dimensions and Connection Sizes

7KR Electrical Defrost Unit Coolers (PN E108318_S)
TABLE 1B: GAS DEFROST UNIT DIMENSIONS AND CONNECTION SIZES
MODEL
NUMBERS
Refrigeration Connections DIMENSIONS (IN)
LIQ SUCT HOT GAS
L W H
KR*14( )-037[ ]{ } 1/2” 5/8” 1/2” 29.13 15.32 15.9
KR*24( )-074[ ]{ }
1/2” 7/8” 1/2” 47.13 15.32 15.9
KR*34( )-111[ ]{ }
1/2” 7/8” 1/2” 65.13 15.32 15.9
KR*44( )-148[ ]{ }
1/2” 1-1/8” 1/2” 83.13 15.32 15.9
KR*54( )-185[ ]{ }
1/2” 1-1/8” 1/2” 101.1 15.32 15.9
KR*64( )-220[ ]{ }
1/2” 1-1/8” 1/2” 119.1 15.32 15.9
KR*16( )-035[ ]{ }
1/2” 5/8” 1/2” 29.13 15.32 15.9
KR*16( )-045[ ]{ }
1/2” 5/8” 1/2” 29.13 15.32 15.9
KR*26( )-090[ ]{ }
1/2” 7/8” 1/2” 47.13 15.32 15.9
KR*36( )-135[ ]{ }
1/2” 7/8” 1/2” 65.13 15.32 15.9
KR*46( )-180[ ]{ }
1/2” 1-1/8” 1/2” 83.13 15.32 15.9
KR*56( )-192[ ]{ }
1/2” 1-1/8” 1/2” 101.1 15.32 15.9
KR*66( )-270[ ]{ }
1/2” 1-1/8” 1/2” 119.1 15.32 15.9
* Replace with ‘D’ or ‘A’ where ‘D’ units are DOE compliant and ‘A’ are for non-regulated applications.
( ) Gas defrost type K, H, G or P. See definition below.
[ ] Replace with the refrigerant letter code refer to the model nomenclature.
{ } Motor type designation, replace with ‘D’ for Dual Speed or ‘V’ for Variable Speed.
TABLE 1C: AIR DEFROST UNIT DIMENSIONS AND CONNECTION SIZES
MODEL
NUMBERS
Refrigeration
Connections
DIMENSIONS (IN)
LIQ SUCT
L W H
KRD16A-040[ ]{ } 1/2” 5/8” 29.13 15.32 15.9
KRD16A-060[ ]{ } 1/2” 5/8” 29.13 15.32 15.9
KRD26A-089[ ]{ } 1/2” 7/8” 47.13 15.32 15.9
KRD26A-125[ ]{ } 1/2” 7/8” 47.13 15.32 15.9
KRD36A-134[ ]{ } 1/2” 7/8” 65.13 15.32 15.9
KRD36A-170[ ]{ } 1/2” 1-1/8” 65.13 15.32 15.9
KRD46A-216[ ]{ } 1/2” 1-1/8” 83.13 15.32 15.9
KRD56A-242[ ]{ } 1/2” 1-1/8”
101.13 15.32 15.9
KRD66A-340[ ]{ } 1/2” 1-3/8” 119.13 15.32 15.9
KRD14A-058[ ]{ } 1/2” 5/8” 29.13 15.32 15.9
KRD24A-096[ ]{ } 1/2” 5/8” 47.13 15.32 15.9
KRD24A-117[ ]{ } 1/2” 5/8” 47.13 15.32 15.9
KRD34A-143[ ]{ } 1/2” 5/8” 65.13 15.32 15.9
KRD34A-173[ ]{ } 1/2” 5/8” 65.13 15.32 15.9
KRD44A-191[ ]{ } 1/2” 5/8” 83.13 15.32 15.9
KRD44A-232[ ]{ } 1/2” 5/8” 83.13 15.32 15.9
KRD54A-290[ ]{ } 1/2” 5/8”
101.13 15.32 15.9
KRD64A-348[ ]{ } 1/2” 5/8”
119.13 15.32 15.9
[ ] Replace with the refrigerant letter code refer to the model nomenclature.
{ } Motor type designation, replace with ‘D’ for Dual Speed or ‘V’ for Variable Speed.
