What to do if analogue output does not work correctly on KRAL Measuring Instruments?
If the analogue output on your KRAL Measuring Instruments isn't functioning correctly, it might be due to an issue with the current between terminals 10 and 6. Verify the supply voltage for both the BEM 200 and the analogue output, ensuring there are no impermissible connections. If necessary, consider using analogue isolators.
What to do if KRAL Measuring Instruments display "0 / zero” as the flow rate?
If your KRAL Measuring Instruments are showing a flow rate of 0, it could be due to a transducer fault. Here’s what to check: * Inspect the wiring. * Consider replacing the pick-up. * If there is a flow (Total is counting) check setup values under menu 2.
How to reset password on KRAL Measuring Instruments?
Setup values for KRAL Measuring Instruments can be protected by a password, as configured in “Menu 6 - OTHER”. If you've set a password, remember that setup values can only be accessed with it. Ensure the password is kept safe, as there's no alternative access method provided.
Why does KRAL BEM 200 display “------” as the flow rate?
The KRAL Measuring Instruments might display “------” as the flow rate because the actual flow rate is too high to be displayed.
General| Housing Material | Stainless steel |
|---|---|
| Output Signal | 4-20 mA, pulse, frequency |
| Power Supply | 24 V DC |
| Process Connection | Flange |
| Protection Class | IP67 |
| Operating Temperature | -20°C to +60°C |
Provides general information about the operating instructions and the electronic unit.
Identifies intended users and required qualifications for operating the unit.
Lists documents that should be consulted alongside these instructions.
Explains the meaning of symbols used throughout the document.
Specifies the intended application and operating limits for the electronic unit.
Describes uses that extend beyond the intended purpose and are considered misuse.
Lists essential safety precautions that must be observed during operation and maintenance.
Presents the physical dimensions and opening specifications of the electronic unit housing.
Illustrates the connection terminals for PNP and NAMUR sensors.
Details the internal electrical connections and terminal functions.
Provides specifications for supply and pulse input/output connections.
Details the parameters for pulse and analog output signals.
Specifies storage, operating temperature, humidity, and protection class.
Describes the display type and weight of the electronic unit.
Covers maximum cable cross-section and data storage method.
Explains the use of the unit with KRAL flow meters and the K-factor.
Details how instantaneous and total flow volumes are calculated and displayed.
Outlines the unit's capabilities for signal processing and output options.
Describes the intended single-line measurement applications with a flow meter.
Identifies the keys on the electronic unit's control panel.
Lists components included in delivery and guides unpacking.
Provides guidance on transporting and storing the unit safely.
Highlights critical safety instructions during installation and removal.
Explains how to install the unit when ordered as an accessory.
Step-by-step instructions for removing the unit from an OME flow meter.
Step-by-step instructions for removing the unit from an OMP flow meter.
Crucial safety instructions to be followed during connection tasks.
Illustrates the electronic unit's connection to OME and OMP flow meters.
Step-by-step guide for connecting the pick-up sensor to the unit.
Instructions for connecting the pulse output signal for external processing.
Details on how to connect the DC power supply to the electronic unit.
Basic checks to perform before putting the electronic unit into operation.
Procedure for safely disconnecting the electronic unit from the power supply.
Describes the three modes: Setup, Programming, and Operator mode.
Details the functions assigned to the SELECT and CLEAR keys.
Explains common procedures like activating setup and changing values.
Defines the purpose and usage of setup and operator modes.
Explains how flow rate, total, and accumulated total are displayed.
Procedure for resetting the total flow value.
Describes how internal alarm conditions are indicated.
Lists all configurable setup functions and variables, including password protection.
Details settings for measurement unit, decimal places, and K-factor for totals.
Covers settings for flow rate measurement unit, time, decimals, and K-factor.
Specifies the output signal type for the meter.
Settings for activating/deactivating and configuring the analog output.
Configuration options for the digital output pulse length and decimal format.
Provides unit information like model, version, serial number, password, and backlight.
Outlines checks for housing, cables, wiring, and process accuracy.
Instructions on how to clean the unit safely.
Guidance on disposing of the electronic unit in an environmentally friendly manner.
Lists common faults, their causes, and recommended solutions.
Describes fastening sets for assembling the unit onto flow meters.
Discusses using alternative power supplies for the unit.
Technical data and cable assignment for the EEN 13 power supply accessory.
