12 Menu description
12.6 Menu 5 - D-OUT
No. Submenu Page (Information) Values Preset
4.5 T.MAX Maximum output signal
Note: The value can be adjusted if the analogue
output is deactivated.
0...9999 5461
* Nominal flow rate of the flow meter
Tab.10: Menu 4 - A-OUT
12.6 Menu 5 - D-OUT
No. Submenu Page (Information) Values Preset
5.1 MODE The mode determines the length of the pulse:
OFF = Pulse output deactivated
SHORT = Max. pulse length 5 ms
LONG = Max. pulse length 100 ms
OFF
SHORT
LONG
OFF
5.2 DECS Display format of the decimal values of the flow rate
per pulse
0
0.1
0.02
0,003
0
5.3 AMNT Flow rate per pulse 0,001...
9999999.
1000
Tab.11: Menu 5 - D-OUT
12.7 Menu 6 - OTHER
No. Submenu Page (Information) Values Preset
6.1 BEM Model:
For support and maintenance, information on the
characteristics of the electronic unit must be
provided. The manufacturer will request this inform-
ation in the event of a serious malfunction.
200 –
6.2 V-NO Software version:
For support and maintenance, information on the
characteristics of the electronic unit must be
provided. The manufacturer will request this inform-
ation in the event of a serious malfunction.
xx.xx.xx –
6.3 S-NO Serial number:
For support and maintenance, information on the
characteristics of the electronic unit must be
provided. The manufacturer will request this inform-
ation in the event of a serious malfunction.
xxxxxxx –
6.4 PIN Password:
All setup values can be password-protected.
Up to 4 digits can be programmed, e.g. 1234.
0000 = no password protection
Note: When a password is set, it must be kept in a
safe place. After setting a password, the setup val-
ues can only be accessed with a password.
0000... 9999 1000
6.5 BL Display backlight ON; OFF ON
Tab.12: Menu 6 - OTHER
Operating instructions
OIE 24en-GB Edition 2022-01
19
