16 Accessories
16.2 Electrical connection
16.2 Electrical connection
16.2.1 Alternative power supply
The electronic unit operates with a power supply of 10 - 30 V DC. If a different voltage is available in
the system, a suitable power supply unit can be used.
16.2.2 Plug-in power supply unit EEN13
The accessory set includes exchangeable connectors that can be used in most countries of the world.
Fig.11: Plug-in power supply unit EEN13
Component Parameter Unit Value
Input Power consumption [W] 20
Input voltage [VAC] 90–264
Frequency [Hz] 47–63
Max. current consumption [A] 0.4.
Leak flow max. [mA] 0.25
Output Output voltage [VDC] 24±2%
Output current max. [mA] 625
Output power [W] 15
Short-circuit protection Continuous (auto recovery)
Overvoltage protection Yes
Environment Operating temperature [°C] 0~+40
Storage temperature [°C] -20°C~+85
Dimensions [mm] 80.6 x 47.9 x 43.3
Weight [g] 130
Tab.14: Technical data EEN13
Cable assignment
Connection Function Color
Output + 24V White
GND Black
