Operating Instructions OIO 14en Edition 07/2017 25
Preservation
Transportation, storage and disposal
Preservation
Preservation has to be carried out additionally under the following conditions:
Tab. 1 Check table for preservation
Preserving the flowmeter
1. Close a connection of the flowmeter with a blind flange.
2. Position the flowmeter vertically.
3. Fill non-corrosive and resin-free oil up to approx. 1 cm under the connection at the top, while turning
the measuring unit slowly, so that the measuring unit also comes into contact with it.
4. Close the upper connection with a blind flange.
5. Apply non-corrosive and resin-free oil to all the plain and unpainted parts of the outer housing.
After about six months storage check the oil level in the flowmeter and if necessary top up oil. Check the
preservation of the outer housing and if necessary apply oil to the parts again.
Notice:
Store the preserved flowmeter cool and dry and protect it against direct sunlight.
Notice:
After a longer storage time the manufacturer recommends that you have the flowmeter recalibrated, see
"Re-calibration of the flowmeters", page 34.
Removing the preservation
Aids:
□ Solvents suitable for the preservative oil
□ Vessel to collect the preservative oil
1. Remove one of the blind flanges.
2. Drain the flowmeter, collecting the preservative oil in a suitable vessel.
3. Remove the second blind flange.
4. Use a solvent to remove the residual oil.
- or -
► Rinse the flowmeter with pumped liquid.
Type of delivery Condition
Standard delivery
□ Storage time exceeding six weeks
□ Unfavorable storage conditions such as high
humidity, salty air, etc.
Delivery with long-term preservation
□ Opened or damaged packaging
WARNING
Risk of injury through emitted preservative oil.
► Wear protective clothing during all the work.
► Open the blind flange carefully in order to reduce any pressure that may exist in the flowmeter.
► Collect the emitted preservative oil safely and dispose of it in an environmentally compatible
manner.
