KRAL OMG 13 - Mounting Instructions OMG 20;32; Removing Seals and Bearings

Operating Instructions OIO 14en Edition 07/2017 37
Mounting instructions OMG 20/32
Maintenance
Mounting instructions OMG 20/32
Removing seals and bearings
Prerequisites:
□ Flowmeter removed from system
□ End connection consisting of socket screws, flanges and seals removed
□ Pick up inserts removed
Fig. 5 Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
039
056
064.1***
064.2
070.1
070.2
128
259
672.1
Distance sleeve
Spacer
Supporting ring
Supporting ring
End cover
End cover
Measuring housing
Pole wheel
Measuring screw large
672.2
739.1
739.2
739.5**
817.1
817.2
817.3
817.4
869.2
Measuring screw small
O-ring
O-ring
O-ring
Deep-groove ball bearing
Deep-groove ball bearing
Deep-groove ball bearing
Deep-groove ball bearing
Circlip
869.4
904.1
904.2
915.1
915.2
915.6
915.7
A
Circlip
Lock washer
Lock washer
Socket screws
Socket screws
Socket screws
Socket screws
Grooved insert pin
**
***
two units if two pick up holes exist
only for OMG 32
915.1
070.1
128
070.2
915.2
739.2
739.1
739.5**
070.1
039
128
869.4
817.4
672.2
817.3
064.2
904.2
915.7
869.2
817.2
672.1
817.1
056
259
915.6
904.1
064.1***
AA039
