KRAL OMG 13 - Type Code

6 OIO 14en Edition 07/2017 Operating Instructions
Type code
Labelling
Labelling
Type code
1 Series
2 Size
3 Sensor technology
4 Function of sensor technology
5 Material of bearing
6 Material of seal
7 Mechanical connection
8 Electrical connection
9 Version index
Fig. 1 Type code
Item Designation Description
1 Series OMG: Universal
2 Size Corresponds to the diameter of the measuring screw large in [mm]
3 Sensor technology B: BEG 43
C: BEG 44
D: BEG 45
E: BEG 45 + BEV 13
F: BEG 47
G: BEG 53
H: BEG 54
X: Special design
4 Function of sensor
technology
A: Without flow direction detection
B: With flow direction detection
C: Without flow direction detection, with temperature compensation
D: With flow direction detection, with temperature compensation
X: Special design
5 Material of bearing A: Steel
B: Hybrid
X: Special design
6 Material of seal A: FPM (FKM)
B: FFPM
C: Low temperature FPM
D: EPDM
X: Special design
7 Mechanical
connection
A: Pipe thread connection BSPP
B: Flange connection DIN
C: Pipe thread connection NPT
D: Flange connection ANSI
E: Flange connection JIS
F: Flange connection SAE
X: Special design
OMG-020.CABABA.0001
3
4
5
2
7
6
8
9
1
