KRAL OMG 13 - Page 47

Operating Instructions OIO 14en Edition 07/2017 47
General drawings
Appendix
Fig. 2 Exploded view OMG 20/32
915.3*
115.1*
739.3*
739.4*
115.2*
915.4*
915.2*
070.2
739.2
128
039
739.1
070.1
597.1
739.5**
915.1*
869.4
817.4
672.2
817.3
064.2
904.2
915.7
869.2
817.2
672.1
817.1
056
259
915.6
904.1
064.1***
