KRAL OMG 13 - Page 9

Operating Instructions OIO 14en Edition 07/2017 9
Technical data
Tab. 3 Additional maximum values when BEG 44 is used
Tab. 4 Additional maximum values when BEG 45 is used
Tab. 5 Additional maximum values when BEG 47D is used
Tab. 6 Additional maximum values when BEG 53A or BEG 54A is used
K2 OMG 13 OMG 20 OMG 32 OMG 52 OMG 68 OMG100 OMG140
Pole number 4 8 12 16 20 28 40
K-factor [P/l] 2432 1280 468 142 79.6 33.6 17.7
Milliliters/pulse [ml/P] 0.411 0.782 2.14 7.04 12.56 29.76 56.50
Pulse frequency
f2 (Q
max
) [Hz] 608 960 1170 1243 1393 1680 2213
f2 (Q
nom
) 405 640 780 828 929 1120 1475
f2 (Q
min
) 4.1 6.4 7.8 8.3 9.3 11.2 14.8
K3 OMG 13 OMG 20 OMG 32 OMG 52 OMG 68 OMG100 OMG140
Pole number 12 16 26 34 42 48 50
K-factor [P/l] 7296 2560 1014 302 167 57.6 22.1
Milliliters/pulse [ml/P] 0.137 0.391 0.99 3.31 5.98 17.36 45.20
Pulse frequency
f3 (Q
max
) [Hz] 1824 1920 2535 2640 2927 2880 2763
f3 (Q
nom
) 1216 1280 1690 1760 1949 1920 1842
f3 (Q
min
) 12.2 12.8 16.9 17.6 19.5 19.2 18.4
Observe the flow range: If the value lies below Q
min
, refer to the
operating instructions of the corresponding pick-up
K1 OMG 13 OMG 20 OMG 32 OMG 52 OMG 68 OMG100 OMG140
Pole number 2 4 6 8 10 14 20
K-factor [P/l] 1216 640 234 71.0 39.8 16.8 8.85
Milliliters/pulse [ml/P] 0.822 1.56 4.27 14.08 25.13 59.52 112.99
Pulse frequency
f1 (Q
max
) [Hz] 304 480 585 621 697 840 1106
f1 (Q
nom
) 203 320 390 414 464 560 738
f1 (Q
min
) 2.0 3.2 3.9 4.1 4.6 5.6 7.4
K4 OMG 13 OMG 20 OMG 32 OMG 52 OMG 68 OMG100 OMG140
Pole number 12 16 26 34 42 73 102
K-factor [P/l] 7296 2560 1014 302 167 87.6 45.1
Milliliters/pulse [ml/P] 0.137 0.391 0.986 3.311 5.988 11.416 22.173
Pulse frequency
f4 (Q
max
) [Hz] 1824 1920 2535 2643 2923 4380 5638
f4 (Q
nom
) 1216 1280 1690 1762 1948 2920 3 758
f4 (Q
min
) 12.2 12.8 16.9 17.6 19.5 29.2 37.6
