3 Identification
3.1 Type code
Item Designation Description
1 Series OME Economy
OMG General/Universal
OMH High Pressure
OMP Performance
OMS Stainless steel
2 Size Corresponds to the diameter of the measuring screw large in [mm]
3 Sensor equip-
ment (pick up)
A BEG 06
B BEG 43
C BEG 44
D BEG 45
E BEG 45 + BEV 13
F BEG 47
G BEG 53
H BEG 54
I BEG 56
J BEG 60-62
X Special design
4 Function of the
sensor equip-
ment
A Without recognition of flow direction
B With recognition of flow direction
C Without recognition of flow direction, with temperature compensation
D With recognition of flow direction, with temperature compensation
X Special design
5 Material of
bearing
A Steel
B Hybrid
C Stainless steel
D All-ceramic
X Special design
6 Material of
seal
A FPM (FKM)
B FFPM (FFKM)
C Low-temperature FPM
D EPDM
X Special design
7 Mechanical
connection
A Thread connection BSPP
B Flange connection DIN
C Thread connection NPT
D Flange connection ANSI
E Flange connection JIS
F Flange connection SAE
X Special design
8 Electrical con-
nection
A Loose cable end
B Cable gland junction box
C Cable gland compact sensor
D Fixing kit for display and processing unit
E Smart Solution version
X Special design
9 Version index For internal administration
Tab.2: Type code
Operating instructions
OIO 14en-GB Edition 2020-01
7
