KRAL OMG Series User Manual

15 Spare parts
15.3 Overview OMG-052/OMG-068
Item No. Part Item No. Part
** Exist twice at two pick up holes
**** Only for OMG-032
Tab.13: List of parts
15.3 Overview OMG-052/OMG-068
915.3
107.1*
739.3
739.4
107.2*
915.4
915.2
080.2
597.2
739.2
128
739.1
080.1
597.1
915.1
869.4
868.4
817.2
672.2
057.2
818.2
064.2
904.2
915.7
739.5**
869.2
868.2
817.1
672.1
057.1
818.1
056
259
064.1
904.1
915.6
054
Item No. Part Item No. Part
054 Distance ring 739.4 O-ring
056 Distance ring 739.5** O-ring
057.1 Threaded ring 817.1 Deep-groove ball bearing
057.2 Threaded ring 817.2 Deep-groove ball bearing
064.1 Supporting ring 818.1 Angular-contact ball bearing
46
OIO 14en-GB Edition 2020-01
