Controlling the Display from the Network (Sending CEC to the
Display)
You can send a CEC command to the display via the network by connecting a laptop or
controller to the Ethernet port on FC-18.
To control the display by Ethernet via the Network:
1. Connect a controller to the FC-18 Ethernet port and the HDMI port to the CEC-
controlled display.
Figure 37: Sending CEC Command via Ethernet Port
2. Send the CEC protocol command to control the display (see Protocol 3000 Commands
on page 63).
The display is controlled by Ethernet via CEC communication to the HDMI port.
Controlling the Display from the Front Panel Buttons (Sending
Ethernet to the Display)
You can turn the display on or off using the front panel buttons.
To control the display using the ON/OFF buttons (sending Ethernet to the display):
1. Connect the Ethernet port and the HDMI port to the Ethernet-controlled display.
Figure 38: Sending Commands by ON/OFF Buttons via Ethernet Port
