Torque Specications
Engine Torque Chart
Water Pump Drain Hole Plug EJOTALtracs
®
Plus 60x14
8 Nm (5.9 ft-lb)*
Bleeder Flange Screw EJOTALtracs
®
6x12
8 Nm (5.9 ft-lb)*
Hose Clamp, Intake Flange M4 2.5 Nm (1.84 ft-lb)
Nozzle, Engine Vent M5 2 Nm (1.5 ft-lb)
Oil Nozzle for Piston Cooling M5 2 Nm (1.5 ft-lb)
Oil Nozzle in Cylinder Head M5 2 Nm (1.5 ft-lb)
Remaining Screws, Engine M5 6 Nm (4.4 ft-lb)
Cam Lever Axial Lock Screw M5 6 Nm (4.4 ft-lb)*
Crankshaft Speed Sensor Screw M5 6 Nm (4.4 ft-lb)*
Gear Position Sensor Screw M5 5 Nm (3.7 ft-lb)*
Oil Filter Cover Screw M5 6 Nm (4.4 ft-lb)
Pressure Plate Screw M5 3 Nm (2.2 ft-lb)*
Shift Drum Retaining Bracket Screw M5 6 Nm (4.4 ft-lb)*
Shift Shaft Sensor Screw M5 6 Nm (4.4 ft-lb)*
Thermostat Case Screw M5 6 Nm (4.4 ft-lb)*
Balancer Shaft Securing Screw M5 5 Nm (3. 7 ft-lb)*
Swing Angle Sensor Screw M5 6 Nm (4.4 ft-lb)*
Starter Motor Cable Nut M6 5 Nm (3. 7 ft-lb)
Engine Remaining M6 Screws M6 10 Nm (7.4 ft-lb)
Alternator Cover Screw M6x30 10 Nm (7.4 ft-lb)
Alternator Cover Screw M6x35 10 Nm (7.4 ft-lb)
Camshaft Bearing Bridge Screw M6 10 Nm (7.4 ft-lb)
Clutch Cable Retaining Bracket Screw M6 10 Nm (7.4 ft-lb)*
Clutch Cover Screw M6 10 Nm (7.4 ft-lb)
Clutch Release Lever Screw M6 10 Nm (7.4 ft-lb)*
Clutch Spring Screw M6 8 Nm (5.9 ft-lb)
Cylinder Head Screw M6 10 Nm (7.4 ft-lb)
Engine Case Screw M6x30 12 Nm (8.9 ft-lb)
Engine Case Screw M6x60 12 Nm (8.9 ft-lb)
Freewheel Ring Screw M6 14 Nm (10.3 ft-lb)*
Ignition Coil Screw M6 8 Nm (5.9 ft-lb)
Locking Lever Screw M6 10 Nm (7.4 ft-lb)*
Main Shaft Bearing Support Screw M6 10 Nm (7.4 ft-lb)*
Oil Pan Screw M6x30 10 Nm (7.4 ft-lb)
Oil Pan Screw M6x35 10 Nm (7.4 ft-lb)
Oil Pump Cover Screw M6 10 Nm (7.4 ft-lb)*
Oil Pump Unit Screw M6 10 Nm (7.4 ft-lb)
Oil/Water Heat Exchanger Screw M6 10 Nm (7.4 ft-lb)*
Shift Drum Locating Screw M6 10 Nm (7.4 ft-lb)*
Shift Lever Screw M6 14 Nm (10.3 ft-lb)*
Shift Shaft Retaining Bracket Screw M6 10 Nm (7.4 ft-lb)*
Starter Motor Screw M6 10 Nm (7.4 ft-lb)
Stator Screw M6 10 Nm (7.4 ft-lb)*
Timing Chain Shaft Screw M6 10 Nm (7.4 ft-lb)
Upper Guide Rail Screw M6 8 Nm (5.9 ft-lb)*
Valve Cover Screw M6 10 Nm (7.4 ft-lb)
Water Pump Cover M6 10 Nm (7.4 ft-lb)*
Water Pump Wheel M6 10 Nm (7.4 ft-lb)*
Nut, Exhaust Flange M8 15 Nm (11.1 ft-lb)***
Oil Nozzle for Clutch Lubrication M8 5 Nm (3. 7 ft-lb)*
Remaining Screws for Engine M8 20 Nm (14.8 ft-lb)
Screw Plug, Locking Screw M8 15 Nm (11.1 ft-lb)
Engine Case Screw M8x45 25 Nm (18.4 ft-lb) †
Engine Case Screw M8x55 25 Nm (18.4 ft-lb) †
Engine Case Screw M8x65 25 Nm (18.4 ft-lb) †
Engine Case Screw M8x90 25 Nm (18.4 ft-lb) †
Knock Sensor Screw M8 20 Nm (14.8 ft-lb)
Oil Pump Idler Gear Screw M8 15 Nm (11.1 ft-lb)*
Tensioning Rail Screw M8 15 Nm (11.1 ft-lb)*
Stud, Exhaust Flange M8 15 Nm (11.1 ft-lb)*
Connecting Rod Bearing Screw M8x0.75 1st stage
5 Nm (3.7 ft-lb)
2nd stage
20 Nm (14.8 ft-lb)
3rd stage
90°
Screw support and
thread oiled
Spark Plug M10 11 Nm (8.1 ft-lb)
Oil Pressure Sensor M10x1 10 Nm (7.4 ft-lb)
Screw Plug, Bearing Support M10x1 12 Nm (8.9 ft-lb)*
Screw Plug, Cam Lever Axis M10x1 8 Nm (5.9 ft-lb)
Screw, Unlocking of Timing Chain
Tensioner
M10x1 8 Nm (5.9 ft-lb)
Coolant Temperature Sensor M10x1.25 10 Nm (7.4 ft-lb)
Cylinder Head Screw M10x1.25 Tightening sequence:
Observe tightening
sequence.
1st stage – 5 Nm
(3.7 ft-lb)
2nd stage – 15 Nm
(11.1 ft-lb)
3rd stage – 90°
4th stage – 90°
Screw support
greased/thread oiled
Screw Plug, Cylinder Head Oil Drain M12x1.5 15 Nm (11.1 ft-lb)
Screw, Rotor M12x1.5 90 Nm (66.4 ft-lb)
Thread greased
Screw Plug, Water Jacket M16x1.5 20 Nm (14.8 ft-lb)*
Nut, Engine Sprocket M20x1.5 120 Nm (88.5 ft-lb)*
Nut, Inner Clutch Hub M20x1.5 135 Nm (99.6 ft-lb)
Plug, Oil Screen M20x1.5 20 Nm (14.8 ft-lb)
Plug, Timing Chain Tensioner M24x1.5 25 Nm (18.4 ft-lb)
Screw Plug, Alternator Cover M24x1.5 8 Nm (5.9 ft-lb)
* Loctite
®
243™
*** Copper paste
† Screw support greased
