28
Electrical
Battery
Location
The 12 V battery is found behind the left side
fairing.
Charging
Use a proper lithium rated battery charger.
(Optimate 12.8/13.4 V 0.8 A charger is
recommended.)
Removal
1. Turn off the Main Switch.
2. Remove the left side fairing
[See pg. 15].
3. Remove screws
F
and
G
.
4. Remove the battery retainer strap.
5. Lift the battery upward and forward to remove
it.
Installation
1. Put the battery in place.
2. Remount the battery retainer strap.
3. Remount the screws
F
and
G
.
4. Remount the left side fairing.
BATTERY INFO
Krämer Motorcycles are factory-
equipped with a lightweight
LITHIUM BATTERY
• Part No: 301153000
• 12.8 V / 4 Ah
Use a proper lithium rated battery
charger to ensure long life.
Wiring Diagram
Visit the link below to download the wiring diagram of the Krämer GP2-890RR.
https://www.kraemer-motorcycles.com/assets/uploads/downloads/Wiring-Diagram-GP2-890RR-2024.pdf
Battery Location
G
F
