Operating and Controlling
VS-42H2 via Front Panel Buttons
VS-42H2 front panel buttons allow you to do the following:
• Locking and Unlocking Front Panel Buttons on page 11.
• Acquiring an EDID from an Output on page 11.
• Muting and Unmuting Output AV on page 12.
• Routing an Input to an Output on page 12.
Locking and Unlocking Front Panel Buttons
You can toggle locking/unlocking the front panel buttons.
To lock front panel buttons:
• Press and hold LOCK for about 3 seconds.
The front panel LOCK button lights and all the panel buttons are nonoperational.
To unlock front panel buttons:
• Press and hold LOCK for about 3 seconds.
The front panel LOCK button no longer lights and all the panel buttons are operational.
Acquiring an EDID from an Output
You can acquire the EDID from OUT 1 or OUT 2 and copy it to any or all of the four inputs to
be stored in non-volatile memory. You can also reset any or all the inputs to the default EDID.
To copy the EDID from Output 1 and/or Output 2 to one or more Inputs:
1. Press the EDID button to enter the EDID setting mode.
The EDID button and all the INPUT SELECTOR buttons light.
If there is no button activity for 10 seconds, the device automatically exits the EDID setting
mode to normal operation, the EDID button no longer lights and any changes made are lost.
2. From the TO OUT 1 (top) row, press each of the Input buttons to deselect or select
which inputs you want to copy the Output 1 EDID.
Each button press toggles the input button’s light on or off.
3. From the TO OUT 2 (bottom) row, press each of the Input buttons to deselect or
select which inputs you want to copy the Output 2 EDID.
Each button press toggles the input button’s light on or off.
