Kreg 720PRO - Removing the Jig from the Docking Station; Removing from a Mounted Docking Station

19
Removing the Jig from the Docking Station
If you use the 700-Series Jig with the optional docking station, you can remove the
jig from the docking station at any time.
Removing a Kreg 700-Series Jig fromaMountedDocking Station
With the jig handle (1) facing you, slide the jig (A) toward you until the jig(A)
disengages from the dock adapters (H). Then lift the jig (A) off the dock
adapters(H).
1
A
H
