6
Dust Collection Accessories
You can use the provided dust collection accessories to capture dust as you drill.
To attach the dust collection accessories:
a. If necessary for the hose diameter you are using, attach the dust adapter (C) to
the wide end of the dust collection blade (B).
Hose diameter Requires dust adapter?
1-1/4" No
1-7/8" No
2-1/2" Yes
b. Insert the narrow end of the dust collection blade (B) into the left or right side of
the jig.
B
C
Note You can leave the dust collection blade and dust adapter attached to the jig
when the jig is not in use.
