3
Pre-Assembly
Review this section before you begin. Ensure that you have all tools and materials on hand.
Compare the package with the items listed in the Recommended Tools and Product Description
sections. If any item is missing or lost, do not use this product. Contact Technical Support or
return the product to the place of purchase.
Recommended Tools (Not Included)
Assembling dock for use with 500-Series Jig: Assembling dock for use with 700-Series Jig:
#2 Phillips screwdriver
No tools are required.
Product Description
A
B
E
D
K
F
C
G
H
I
J
Part Description Part Description
A Dock-base back for 500-Series Jig F Adjustable stop arm
B Dock-base platform for 500-Series Jig G Adjustable stop knob
C Dock-base screws (2) for 500-Series Jig H Adjustable stop base
D Dock adapters for 700-Series Jig (2) I Adjustable stop base wedge
E Material support wings (2) J Adjustable stop square nut
K KPHA760 Pocket-hole jig clamp
