Servicing the Timeclock
Series 4000 Badge Timeclock User’s Guide 4-27
4. Disconnect the battery charger board from the timeclock’s main board.
5. Trace the wires back to the charger board.
Number Description
1 Battery charger board cable
2 Charger board connection to the main board
