Servicing the Timeclock
Series 4000 Badge Timeclock User’s Guide 4-37
3. On the outside of the timeclock cover, press the two spacers onto the tops of
the channels that hold the screws for the reader cover.
4. Position the reader cover back into place and tighten the two screws.
Number Description
1 Badge reader spacers
2 Badge reader cover
