4 Description of the Pump (Set)
16 of 64
KWP-Bloc
Position Code Description
27-29 BH Close-coupled, horizontal
BV Close-coupled, vertical
30-32 Motor rating P
N
[kW]
7 7
33 Number of motor poles
4.3 Name plate
KSB SE & Co. KGaA
Johann-Klein-Straße 9
67227 Frankenthal
ZN 3804 - E 37 X 52
Q
n
H
P-No.
Mat. No. 01220221
KWPK125-100-0250 GGGG10
2018
0520-5-P-10000-31
997125086300550001
21.0
m³/h
1420
1/min
13.0
m
1
2
3
4
5
6
7
8
9
Fig.1: Name plate (example)
1 Type series, size, material, and
design version
2 Customer-specific information
(optional)
3 KSB order number and KSB order
item number
4 Flow rate
5 Speed 6 Year of construction
7 Head 8 Pump input power (optional)
9 Further required information
(optional)
4.4 Design details
Design
▪ Volute casing pump
▪ Radially split volute casing
▪ Close-coupled design
▪ Pump casing fitted with a wear plate
▪ Single-stage
▪ Single-entry
