KWP-Bloc
Size Suction nozzle Discharge nozzle
F
x
F
y
F
z
F
res
M
x
M
y
M
z
F
x
F
yTens+
F
yCom
pr-
F
z
F
res
M
x
M
y
M
z
[N] [N] [N] [N] [Nm] [Nm] [Nm] [N] [N] [N] [N] [N] [Nm] [Nm] [Nm]
065-050-0201 3145 2065 2515 3235 2065 1525 1080 1527 990 1975 1255 1975 1255 990 630
080-065-0200 3860 2515 3055 3950 2605 1975 1345 2515 1615 3145 2065 3235 2065 1525 1080
080-065-0201 3860 2515 3055 3950 2605 1975 1345 2515 1615 3145 2065 3235 2065 1525 1080
080-065-0315 3860 2515 3055 3950 2605 1975 1345 2515 1615 3145 2065 3235 2065 1525 1080
080-065-0313 3860 2515 3055 3950 2605 1975 1345 2515 1615 3145 2065 3235 2065 1525 1080
100-080-0250 4850 3145 3860 4940 3595 2695 1795 3055 1975 3860 2515 3950 2605 1975 1345
100-080-0251 4850 3145 3860 4940 3595 2695 1795 3055 1975 3860 2515 3950 2605 1975 1345
100-080-0311 4850 3145 3860 4940 3595 2695 1795 3055 1975 3860 2515 3950 2605 1975 1345
100-080-0315 4850 3145 3860 4940 3595 2695 1795 3055 1975 3860 2515 3950 2605 1975 1345
125-100-0250 6645 4310 5300 6825 4940 3770 2515 3860 2425 4850 3145 5030 3595 2695 1795
125-100-0251 6645 4310 5300 6825 4940 3770 2515 3860 2425 4850 3145 5030 3595 2695 1795
125-100-0253 6645 4310 5300 6825 4940 3770 2515 3860 2425 4850 3145 5030 3595 2695 1795
125-100-0315 6645 4310 5300 6825 4940 3770 2515 3860 2425 4850 3145 5030 3595 2695 1795
5.4 Enclosure/insulation
WARNING
The volute casing and casing/discharge cover take on the same temperature as the
fluid handled
Risk of burns!
▷ Insulate the volute casing.
▷ Fit protective equipment.
5.5 Electrical connection
DANGER
Electrical connection work by unqualified personnel
Risk of fatal injury due to electric shock!
▷ Always have the electrical connections installed by a trained and qualified
electrician.
▷ Observe regulations IEC 60364 and, for explosion-proof models, EN60079.
WARNING
Incorrect connection to the mains
Damage to the mains network, short circuit!
▷ Observe the technical specifications of the local energy supply companies.
1. Check the available mains voltage against the data on the motor name plate.
2. Select an appropriate starting method.
NOTE
A motor protection device is recommended.
