9 Related Documents
58 of 64
KWP-Bloc
Part No. Comprising Scope of supply
210 210 Shaft
904.30 Grub screw
932.20 Circlip
940.01 Key
950.10 Spring
230 230 Impeller
321.01 321.01 Deep groove ball bearing
411.77 411.77 Joint ring
504.54
21)
504.54 Spacer ring
509 509 Intermediate ring
412.12 O-ring
914.02/.03 Hexagon socket head cap screw
513.11 513.11 Insert ring
412.11 O-ring
524.01 524.01
22)
Shaft protecting sleeve
412.06 O-ring
639
23)
411.25/.27 Joint ring
639.N1 Oil level gauge, complete
644 Lubricating ring
710.N1/.N2 Pipe
720/731.N1 Barrel nipple
731.N6 Pipe union
731.N2/.N3/.N4/.N5 Angle
903.25 Screw plug
680.01 680.01 Guard
800 800 Motor, complete
906 906 Impeller screw
412.03 O-ring
99-9 99-9 Set of sealing elements
411.01/.02/.03/.10/.12/.13/.
16/.17/.77
Joint ring
412.03/.05/.06/.08/.11/.75 O-ring
Table23: List of components for mechanical seal 4KBL
Part No. Comprising Scope of supply
433 412.52/.53 O-ring
472.53 Primary ring
472.52 Primary ring
473 Primary ring carrier
477 Spring
487 Mating ring carrier
523 Shaft protecting sleeve
Table24: List of components for mechanical seal MG1-G6
Part No. Comprising Scope of supply
433 412.55 O-ring
472.54 Primary ring
21) On pumps with standardised mechanical seal only
22) This is part of mechanical seal 4KBL
23) On pumps with oil reservoir only
