4 Description
4.1 General description
PumpDrive is a modular, self-cooling frequency inverter which enables the motor
speed to be varied continuously by means of analog standard signals, a field bus or
the control panel.
4.2 Designation
Example: 5 018K50 AH P SI 2
Table 6: Key to the designation
2)
Code Description
5 Mounting option, e.g. 5 = Motor mounting (factory-set)
018K50 Rated power, e.g. 018K50 = 18.5 kW
AH Function and control panel, e.g. AH = Advanced with
graphical control panel
P Field bus module, e.g. P = Profibus
SI Parameterisation of motor, e.g. SI = Siemens
2 Parameterisation of number of poles, e.g. 2 = 2 poles
4.3 Name plate
IP55
PumpDrive
3PH 380 : 480 VAC
ID No 48879513
50-60 Hz
S/N 10304lJM0000Z
0105000180
17,4 A
7,5 KW
INPUT:
3007K50 BH0000
1
2
3
4
Fig. 4: Name plate (example)
1 Enclosure 2 Type series, size
3 Ident. number 4 Serial number
4.4 Functions
Table 7: Functions
Functions Design
Basic Advanced
Protective functions
Thermal motor protection by PTC thermistors ✘ ✘
Electrical motor protection by overvoltage/undervoltage monitoring ✘ ✘
Dynamic overload protection by speed limitation (i
2
t control) ✘ ✘
Dry running protection (sensorless) - ✘
Dry running protection (external control signal) ✘ ✘
Characteristic curve control
✘
3)
✘
4)
Open-loop control
Open-loop control mode via setpoint specification ✘ ✘
User-definable speed (0 to 70 Hz for PumpDrive, 0 - 140 Hz for PumpDrive S) ✘ ✘
Sleep mode ✘ ✘
2)
See type series booklet for detailed description of designation.
3)
Based on monitoring of the effective motor power
4)
Based on the current flow rate (measured or estimated).
