KSB PumpDrive - Selection List

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
4-2-1-1 Device Ser No Serial
number of device
0 0 All
4-2-1-2 SW Version
Software version
0 0 All
4-2-1-3 Device Type
Device type
0 0 All
4-2-1-4 Dev Type Code
Code of device type
0 0 0 0 All
4-2-1-5 Bin File Vers
Version of binary
file
0 0 0 0 Service
4-2-1-6 Prog Lang 1
Freely
programmable
language 1
0 0 Service
4-2-1-7 Prog Lang 2
Freely
programmable
language 2
0 0 Service
4-2-1-8 Bin File Chksum
Checksum of binary
file
0 0 0 65535 Service
4-2-1-9 Bin File Length
Size of binary file
0 0 0 65535 Service
10.1 Selection list
Table 110: Selection list
Selection value
Selection list
I II III IV V
1 None
(No Function)
None % OFF 1,0 kHz
2 Reset
(reset after alert;
CAUTION: Possible restart)
PDrive Ready 2.5% 1,5 kHz
3 Start System
(system start for multiple
pump configuration)
Ready/No Warn Hz 5% 2,0 kHz
4 Start
(pump start in automatic
mode)
Operation kW 7.5% 2,5 kHz
5 Selection of Ramp
(selection of ramp 1 or 2)
Operation/No Warn kWh 10% 3,0 kHz
6 None (No Function) Setpt/No Warn hex 12.5% 3,5 kHz
7 Pset OutF Bit 0
(bit 0 for digital selection of
a fixed speed)
Alert mA 15% 4,0 kHz
8 Pset OutF Bit 1
(bit 1 for digital selection of
a fixed speed)
Alert or Warn A 17.5% 4,5 kHz
9 Preset Setpt +
(setpoint increase via digital
pulses)
Current limitation V 20% 5,0 kHz
10 Preset Setpt -
(setpoint decrease via digital
pulses)
Current range 10-s 22.5% 5,5 kHz
10 Parameter lists
PumpDrive
129 of 162
