11 Trouble-shooting
DANGER
Unintentional start-up
Danger of death from electric shock!
▷ Disconnect the PumpDrive from the power supply before performing any
maintenance or installation work.
▷ Ensure that the PumpDrive cannot be switched on again during maintenance
and installation work.
NOTE
Depending on the combination of settings, PumpDrive could conceivably restart
automatically after acknowledgement/reset or when the cause of the malfunction
or fault has been eliminated.
Reset PumpDrive to factory settings prior to implementing all fault rectification
measures (⇨ Section 7.3.1 Page 93) .
11.1 Faults/Malfunctions: Trouble-shooting
WARNING
Improper work to remedy faults at the pump (set)
Risk of injury!
▷ For any work to remedy faults at the pump (set) observe the relevant
information in this manual or in the relevant accessory manufacturer's
documentation.
If problems occur that are not described in the following table, consultation with
KSB’s customer service is required.
Mains fuse rating too small for the nominal mains current.
PumpDrive does not start
PumpDrive runs unevenly
Max. speed not reached.
PumpDrive running at maximum speed only
PumpDrive running at minimum speed only
No 24 V supply.
Wrong direction of rotation of the motor.
Fault message/protective tripping.
Table 111: Faults
A B C D E F G H I Possible causes Remedy
✘
✘
No voltage Check the mains voltage; check the mains fuses
✘
No enable Insert jumper/enable via field bus
✘ ✘
Mains cables connected
incorrectly/
Fault in supply line
Check wiring
✘
Mains fuse rating too small for
PumpDrive input current
(⇨ Section 5.4.2.1 Page 21)
✘ ✘
No setpoint signal (internal/
external)
Check the setpoint signal (internal/external)
✘ ✘
✘ Permissible voltage range
undershot/exceeded
Check the mains voltage; supply PumpDrive with the
specified voltage (via transformer, if necessary)
✘
Wrong direction of rotation
set
Change the direction of rotation.
✘ ✘ ✘
✘
✘ PumpDrive overload Reduce the power input by lowering the speed;
check the motor/pump for blockages.
A
B
C
D
E
F
G
H
I
