KSB PumpDrive - 10 Parameter lists

10 Parameter lists
Table 108: Key
Abbreviation used Description
EP Single-pump operation
MP Multiple pump configuration
Selection list (⇨ Section 10.1 Page 129)
bg Depending on the size
If a parameter's access level is not explicitly specified, the parameter is always
assigned the customer access level (⇨ Section 6.2.5.3.2 Page 46) .
Table 109: Overview of parameters
Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
1 Operation
Main menu for operation
1-1 Operation
1-1-1 Operation
Submenu for
operation
- - - - - - -
1-1-1-1 Tot Hrs Volt S
Total voltage supply
time
0 0 0 0 h All -
1-1-1-2 Operating Hours
Display of operating
hours
0 0 0 0 h All -
1-1-1-3 kWh Counter
Display of energy
consumption
0 0 0 0 kWh All -
1 -1-1-4 No of Power-ups
Number of starts
0 0 0 0 - All -
1-1-1-5 Rst kWh Counter
Reset energy meter
1 1 - - - Customer No Reset
Reset
1-1-1-6 Rst Op Hours
Reset operating
hours
1 1 - - - Service No Reset
Reset
1-2 Motor
Motor menu
1-2-1 Motor
Submenu for motor
specification
- - - - - -
1-2-1-1 Power [kW]
Display of motor
power rating in kW
0 0 0 0 kW All -
1-2-1-2 Power [HP]
Display of motor
power rating in HP
0 -
0
0 0 HP All -
1-2-1-3 Motor Voltage
Display of motor
voltage
0 0 0 0 V All -
1-2-1-4 Frequency
Display of motor
frequency
0 0 0 0 Hz All -
1-2-1-5 Motor Current
Display of motor
current
0 0 0 0 A All -
1-2-1-6 Speed [RPM]
Display of speed in
RPM
0 0 0 0 rpm All -
1-3 Signals
Menu for signals
