KSB PumpDrive - Page 105

Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
1-3-1 Process
Submenu for
ongoing process
- - - - - - -
1-3-1-1 Feedback [Unit]
Actual value of
feedback in
corresponding unit
0 0 0 0 3-2-2-1 All -
1-3-1-2 Feedback %
Actual value of
feedback in percent
0 0 0 0 % All -
1-3-1-3 Setpoint [Unit]
Display of setpoint
in corresponding
unit
0 0 0 0 3-2-2-1 All -
1-3-1-4 Setpoint %
Display of setpoint
in percent
0 0 0 0 % All -
1-3-1-5 Anlg IN1 [Unit]
Display of analog
input 1 in
corresponding unit
0 0 0 0 3-8-2-6 All -
1-3-1-6 Anlg IN2 [Unit]
Display of analog
input 2 in
corresponding unit
0 0 0 0 3-8-3-6 All -
1-3-1-7 Pressure P1
Display of pressure
P1
0 0 0 0 3-2-2-3 All -
1-3-1-8 Pressure P2
Display of pressure
P2
0 0 0 0 3-2-2-3 All -
1-3-1-9 Q [Unit]
Display of flow rate
Q in corresponding
unit
0 0 0 0 3-2-2-2 All -
1-3-1-10
35)
Q %
Display of flow rate
Q in percent
0 0 0 0 % All -
1-3-1-11 Temperature
Display of
temperature
0 0 0 0 °C All -
1-3-2 Inputs&Outputs
Submenu for
displaying inputs
and outputs
- - - - - - -
1-3-2-1 Digital I/ODigital
Display of status of
inputs and outputs
0 0 0 0 hex All -
1-3-2-2 Analog IN 1 Display
of actual value of
analog input 1
0 0 0 0 % All -
1-3-2-3 Analog IN 2 Display
of actual value of
analog input 2
0 0 0 0 % All -
1-3-2-4 Analog OUT 1
Display of actual
value of analog
output
0 0 0 0 % All -
35)
Selection Is Inactive
10 Parameter lists
PumpDrive
105 of 162
