Parameter Description Factory
setting
Setting Unit Access level Possible settings
EP MP Min. Max.
1-4 PumpDrive
PumpDrive menu
1-4-1 Status
Submenu for
displaying the
current status of
PumpDrive
- - - - - - -
1-4-1-1 DC Link Voltage
Actual value of DC
link voltage
0 0 0 0 V All -
1-4-1-2 Heat Sink Temp
I Display of heat sink
temperature
0 0 0 0 °C All -
1-4-1-3 PCB Temp
Display of internal
temperature
0 0 0 0 °C All -
1-4-2 Local Bus
Submenu for
internal bus (local
bus)
- - - - - - -
1-4-2-1 System Setpoint
Display of internal
setpoint
0 0 0 0 Factory -
1-4-3 Bus Readout
Submenu for bus
diagnostics
- - - - - - -
1-4-3-1 Control Word
Control word
0 0 0 0 hex Customer -
1-4-3-2 Alarm Word
Alert word
0 0 0 0 hex Customer -
1-4-3-3 Warning Word
Warning word
0 0 0 0 hex Customer -
1-4-3-4 Status Word
Status word
0 0 0 0 hex Customer -
1-5 Pump
Menu for pump
1-5-1 Flow Rate Meas
Submenu for flow
rate (Q)
measurement
- - - - - - -
1-5-1-1 Sys Flow Rate
Actual value of total
flow rate of system
0 0 0 0 m3/h All -
1-5-1-2 Flow Rate Pump1
Actual value of flow
rate Q of pump 1
0 0 0 0 m3/h All -
1-5-1-3 Flow Rate Pump2
Actual value of flow
rate Q of pump 2
0 0 0 0 m3/h All -
1-5-1-4 Flow Rate Pump3
Actual value of flow
rate Q of pump 3
0 0 0 0 m3/h All -
1-5-1-5 Flow Rate Pump4
Actual value of flow
rate Q of pump 4
0 0 0 0 m3/h All -
1-5-1-6 Flow Rate Pump5
Actual value of flow
rate Q of pump 5
0 0 0 0 m3/h All -
1-5-1-7 Flow Rate Pump6
Actual value of flow
rate Q of pump 6
0 0 0 0 m3/h All -
10 Parameter lists
106 of 162
PumpDrive
