7 Commissioning/shutdown
Ensure that the following requirements are met prior to commissioning:
▪ The pump has been vented and primed with the fluid to be handled.
▪ Flow through the pump is in the design direction specified in order to avoid
generator operation of PumpDrive.
▪ A sudden start-up of the motor or pump set does not result in personal injury or
damage to machinery.
▪ No capacitive loads, for example for reactive current compensation, are
connected to the outputs of the device.
▪ The mains voltage is in the range approved for PumpDrive.
▪ PumpDrive has been properly connected to the power supply. (⇨ Section 5.4 Page
20)
▪ All enable and start commands that start PumpDrive are deactivated (digital
input 1 for single-pump operation and digital inputs 1 and 2 for multiple pump
operation).
▪ No voltage is applied to the power supply module of PumpDrive.
▪ PumpDrive or the pump set must not be loaded above the permissible nominal
power.
▪ If PumpDrive is going to be used in multiple pump operation, note (⇨ Section
7.1.3 Page 62) prior to commissioning.
7.1 Pump operation
7.1.1 Single-pump operation
7.1.1.1 Setting motor parameters
Motor-mounted PumpDrive model:
The motor parameters have been set at the factory.
Cabinet-mounted or wall-mounted PumpDrive model:
The factory-set motor parameters must be compared with the data provided on the
motor rating plate and adjusted, if required.
Table 45: Motor parameters
Parameter Description Possible settings Reference
to
Factory setting
3-3-2-1
Nominal power 0,55..45 [kW]
Depending on the size
3-3-2-2
Nominal voltage 342..528 [V]
3-3-2-3
Nominal frequency 45..65 [Hz]
3-3-2-4
Nominal motor current 0,1..999 [A]
3-3-2-5
Nominal speed 300..3600 [rpm]
3-3-2-6
Nominal cos phi 0,30 - 0,99
3-3-5-1
Enable/disable thermal motor
protection (PTC)
No Protection
PTC Protection
PTC Protection
3-5-3-4
Output frequency in manual mode 0..100 [100%]
3-11-4-1
0 %
3-6-1-1
Direction of rotation of the motor Clockwise
Anti-clockwise
Clockwise
3-6-1-2
Lower limit for motor frequency 0..100 [100%]
3-11-4-1
50 %
3-6-1-3
Upper limit for motor frequency 0..100 [100%]
3-11-4-1
100 %
3-11-4-1
Maximum output frequency 1..70 [Hz]
50 Hz
7.1.1.2 Entering the setpoint/setting the setpoint unit
The setpoint can be entered via 5 different sources without this having to be
parameterised beforehand. The setpoint can be specified via:
7 Commissioning/shutdown
PumpDrive
49 of 162
