Selection value
Selection list
I II III IV V
11 None
(No Function)
Current Too High h 25% 6,0 kHz
12 Pset AOUT Bit 0
(bit 0 for selection of the
output variable on the
analog output)
Current Too Low °C - 6,5 kHz
13 Pset AOUT Bit 1
(bit 1 for selection of the
output variable on the
analog output)
Frequency range K - 7,0 kHz
14 - Freq Too High rpm - 7,5 kHz
15 - Freq Too Low m - 8,0 kHz
16 - Power Range ft - -
17 - Power Too High HP - -
18 - Power Too Low W/m2 - -
19 - An IN1 Range m/s - -
20 - An IN1 Too High ft/s - -
21 - An IN1 Too Low l/s - -
22 - An IN2 Range l/min - -
23 - An IN2 Too High l/h - -
24 - An IN2 Too Low kg/s - -
25 - Thermal Warn kg/min - -
26 - Rdy/No Temp Wrn kg/h - -
27 - Rdy/No Line Wrn m3/s - -
28 - Rdy/V Range OK m3/min - -
29 - No Alert m3/h - -
30 - Drive MAN Mode GPM - -
31 - Drive AUTO Mode gal/s - -
32 - Setpoint OK gal/min - -
33 - Actual Value OK gal/h - -
34 -
Sleep, Stand-by
36)
lb/s - -
35 - AN > max P, OFF < min lb/min - -
36 - - lb/h - -
37 - - CFM - -
38 - - ft3/s - -
39 - - ft3/min - -
40 - - ft3/h - -
41 - - mbar - -
42 - - bar - -
43 - - Pa - -
44 - - kPa - -
45 - - m WC - -
46 - - m Hg - -
47 - - in Hg - -
48 - - ft Hg - -
49 - - psi - -
50 - - Zb/in - -
51 - - kg/m3 - -
52 - - W - -
36)
Selection Is Inactive
10 Parameter lists
