Table 103: Parameters for the relay output
Parameter Description Possible settings Factory setting
3-7-2-1
Function of digital OUT
1
Selection list II (⇨ Section 10.1 Page
129)
31
3-7-2-2
Time delay between
event and response (on
time delay)
3 - 30 (time delay factor
34)
)
3
3-7-2-3
Time delay between
event and response (off
time delay)
3 - 30 (time delay factor
34)
)
3
3-7-3-1
Function of digital OUT
2
Selection list II (⇨ Section 10.1 Page
129)
4
3-7-3-2
Time delay between
event and response (on
time delay)
3 - 30 (time delay factor
34)
)
3
3-7-3-3
Time delay between
event and response (on
time delay)
3 - 30 (time delay factor
34)
)
3
7.4.3 Analog inputs
Parameters for analog input 1
Table 104: Parameters for analog input 1
Parameter Description Possible settings Factory setting
3-8-2-1
Parameter setting for
Analog IN 1
Current
Voltage
2
3-8-2-2
Analog IN 2 Low
voltage
0 (V) to Analog IN 1 High voltage
(3-8-2-3)
0
3-8-2-3
Analog IN 1 High
voltage
Analog IN 1 Low voltage
(3-8-2-2)
to 10
(V)
10
3-8-2-4
Analog IN 1 Low
current
0 to Analog IN 1 High current
(3-8-2-5)
(mA)
4
3-8-2-5
Analog IN 1 High
current
Analog IN 1 Low current
(3-8-2-4)
to 20
(mA)
20
3-8-2-6
Unit of Analog IN 1 Selection list III (⇨ Section 10.1 Page
129)
1
3-8-2-7
Low value for Analog
IN 1
0 to Analog IN 1 High
(3-8-2-8)
in
Analog IN 1 Unit
(3-8-2-6)
0
3-8-2-8
High value for Analog
IN 1
Analog IN 1 Low
(3-8-2-7)
to 9999 in
Analog IN 1 Unit
(3-8-2-6)
100
3-8-2-9
Analog IN 1 Filter time
constant
0,1..10 (s)
If signal smoothing is required, the
signal can be filtered by lengthening
the time constants. This has the same
effect as a low-pass filter.
0,1
3-8-2-10
Analog IN 1 (Scaling
factor)
0,5..2
By changing the scaling, you can alter
the setting range for the input signal
by the required factor.
1
3-8-2-11
Description of Analog
IN 1
Process
Pressure P1
Pressure P2
Q
Temperature
1
34)
Approximate time delay factor in unit [s]
7 Commissioning/shutdown
PumpDrive
95 of 162
