value range of the source is mapped linearly to the value range of the output voltage
(
3-8-4-5
and
3-8-4-6)
). If the digital inputs are not wired, the operating parameter in
accordance with source 1 is output. The maximum switch-over speed between the
individual sources for the analog output is 100 ms (10 Hz).
Table 107: Analog output sources
Bit 1 Bit 0 Analog output source
0 V 0 V Source 1
0 V 24 V Source 2
24 V 0 V Source 3
24 V 24 V Source 4
