2 SETUP 8
E00475-01
– Preassemble the hand guards on the left and right.
S01461-10
– Mount the left hand guard.
– Mount the right hand guard.
S01459-01
– Secure the handlebar cushion with two cable ties.
– Install the front fender. ( p. 24)
– Install the front wheel. ( p. 20)
(XC‑W US, XC‑W Six Days US, All 250/300 EU/AU/US models)
– Remove the battery. ( p. 21)
– Recharge the battery. ( p. 22)
(All XC‑W/XC‑W Six Days models)
– Install the headlight mask with the headlight. ( p. 25)
(All EXC/EXC Six Days models)
– Remove the fuel tank. ( p. 17)
S01393-11
– Position turn signal cable harness.
–
Insert the indicator lamp with the black and violet cable colors into socket
.
