KTM 150 SX 2021 - Chassis Tightening Torques

TECHNICAL DATA 21
139
21.10 Chassis tightening torques
Screw, switch-off button M3 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, service hour counter M4 0.8 Nm (0.59 lbf ft)
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screws on main silencer M5 7 Nm (5.2 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, absorbing element on frame M6 6 Nm (4.4 lbf ft)
Screw, absorbing element on mani-
fold
M6 6 Nm (4.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine brace on engine M8x20 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine brace on frame M8x15 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold M8 15 Nm (11.1 lbf ft)
Screw, subframe bottom M8x18 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8x20 35 Nm (25.8 lbf ft)
Loctite
®
2701™
