6 CONTROLS
18
6.9 Fuel tap (All SX models)
K01128-10
The fuel tap is on the left side of the fuel tank.
Open or close the fuel supply to the carburetor using tap han-
dle
1
on the fuel tap.
Possible states
• Fuel supply closed OFF – Fuel cannot flow from the fuel tank
to the carburetor.
• Open fuel supply ON – Fuel can flow from the fuel tank to the
carburetor. The fuel tank empties completely.
6.10 Fuel tap (125 XC US)
K00488-10
The fuel tap is on the left side of the fuel tank.
Open or close the fuel supply to the carburetor using tap han-
dle
1
on the fuel tap.
Possible states
• Fuel supply closed OFF – Fuel cannot flow from the fuel tank
to the carburetor.
• Open fuel supply ON – Fuel can flow from the fuel tank to the
carburetor. The fuel tank empties down to the reserve level.
• Fuel reserve supply open RES – Fuel can flow from the fuel
tank to the carburetor. The fuel tank empties completely.
