6 CONTROLS
20
6.13 Kick starter lever
401954-10
Kick starter lever
1
is fitted on the right side of the engine.
The kick starter lever can be swiveled.
Info
Before riding, swing the kick starter lever inwards towards
the engine.
6.14 Foot brake lever
401956-10
Foot brake lever
1
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.15 Plug-in stand (All SX models)
H02629-10
The holder for the plug-in stand
1
is the left side of the wheel
spindle.
The plug-in stand is used to park the motorcycle.
The plug-in stand is used as a fork locker when transporting the
motorcycle.
Info
Remove the plug-in stand before riding.
6.16 Side stand (125 XC US)
401943-10
The side stand
1
is located on the left of the vehicle.
