CONTROLS 6
19
6.11 Choke
K01129-10
(All SX models)
Choke
1
is fitted on the left side of the carburetor.
K01204-10
(125 XC US)
Choke
1
is fitted on the left side of the carburetor.
Activating the choke function frees a drill hole in the carburetor
through which the engine can draw extra fuel. This results in a
richer fuel-air mixture, which is needed for a cold start.
Info
If the engine is warm, the choke function must be deacti-
vated.
Possible states
• Choke function activated – The choke lever is pulled out to
the stop.
• Choke function deactivated – The choke lever is pushed in to
the stop.
6.12 Shift lever
401950-10
Shift lever
1
is mounted on the left of the engine.
401950-11
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
